At present, the main type of cross-linked cable terminals used for voltage levels of 110-345kV abroad is prefabricated rubber stress cone terminals (referred to as prefabricated terminals), while higher voltage level cross-linked cable terminals use silicone oil impregnated thin film capacitor cone terminals (referred to as capacitor cone terminals). Below, Anhui Yifala Electric Power Technology will introduce to you the basic knowledge of low-voltage cable accessories:

Outdoor terminal: a terminal used when exposed to direct sunlight, climatic conditions, or both.

GIS terminal: a cable terminal installed inside a gas insulated enclosed switchgear with SF6 gas as the external insulation.

Oil immersed terminal: a cable terminal installed in the liquid insulated part of the oil immersed transformer tank with insulating oil as the outer insulation.

Direct connector: an accessory that connects two cables to form a continuous circuit, used in situations where the cable line joint is directly grounded.

Insulation joint: a joint that separates the metal sheath, grounding metal shield, and insulation shield of a cable from the electrical connection. It is used for cross interconnection of metal sheaths in cable lines to reduce sheath loss.

Integrated prefabricated rubber insulation: It integrates stress cones, umbrella skirts, and insulation layers into a single prefabricated component.
